Inhalt   Schlepperindex


824

  Infotext ProspekteInfo Bilder



Bildergalerie
(Picture Gallery)


  Baujahre
(Built Years)
  1971-1974




  Stück
(Built Units)
  5558
  Motor
(Engine)
  IHC D-239
IHC D-246 ab 03.1973
  Art / Zyl.
(Type/Cylinder)
  4-Zyl.-Diesel
  Hubraum
(Displacement)
  3911 cm³
4034 cm³
  U/min.
(rpm)
  2200   Infotext BilderInfo Bilder
  PS
(Engine-HP)
  74
75

  Getriebe
(Transmission)
  8+4 Synchron
  Bereifung
(Tyres front/rear)
  7.50-18 / 14-34 (2 WD)
10-24 / 14-34 (4 WD)
  Gewicht
(Weight)
  3145 kg (2 WD)
3450 kg (4 WD)
  Seriennummer
(Serial-No´s)
  D010001 D001000 -
D010001 D
005559

  Ab 1972 mit Aluminium-Kühlergrill
From 1972 with aluminium grille.

© matbush Januar 2016
